Кагуя на орбите Луны

The Japan Aerospace Exploration Agency (JAXA) carried out an observation using two onboard sensors of the Moon Explorer "KAGUYA" (SELENE,) the Terrain Camera (TC) and Multi-band Imager (MI,) on November 3, 2007, processed the acquired data, and confirmed they were functioning properly. The observation was part of the initial functional verification of the KAGUYA, which had been injected into the Moon's orbit at an altitude of about 100 km. In a global first, both three-dimensional (stereo) observations of the Moon by the TC with a 10-meter aerial resolution and a multi-band observations by the MI with a 20-meter aerial resolution of the Moon's backside and near polar were taken.

Terrain Camera (TC)
The Terrain Camera (TC) can observe the day-time side of the Moon using two cameras that respectively face the slightly diagonal front and back sides of the straight down direction of the satellite. It can take three-dimensional (stereo) images of the Moon's globe with a world-leading super high definition of 10 m.

20071116_kaguya_tc02cle_e.jpg @ www.jaxa.jp [кеш]

20071116_kaguya_tc02_e.jpg @ www.jaxa.jp [кеш]

Figure 2: Comparison between the KAGUYA TC image and the Clementine image
You can see the comparison between the image taken by the KAGUYA TC cut out from the TC's first image data (the area encircled by the yellow dot square in Figure 1) and the image shot by the high aerial resolution camera onboard the Clementine Satellite. In the TC camera image, you can see that the smaller craters (10-90 meters in size) and the minute structure of the inside of a crater.

20071116_kaguya_mi03bands.jpg @ www.jaxa.jp [кеш]

Multi-band Imager
(750 nm single-band image with 20 m resolution)

JAXA | KAGUYA (SELENE) Observation by Terrain Camera (TC) and Multi-band Imager (MI)

Japan Aerospace Exploration Agency (JAXA) The Japan Aerospace Exploration Agency (JAXA) carried out an observation using two onboard sensors of the Moon Explorer "KAGUYA" (SELENE,) the Terrain Camera (TC) and Multi-band Imager (MI,) on November 3, 2007, processed the acquired data, and confirmed they were functioning properly. The observation was part of the initial functional verification of the KAGUYA, which had been injected into the Moon's orbit at an altitude of about 100 km. In a global first, both three-dimensional (stereo) observations of the Moon by the TC with a 10-meter aerial resolution and a multi-band observations by the MI with a 20-meter aerial resolution of the Moon's backside and near polar were taken. // Дальше — www.jaxa.jp
